Specifications

Electrical Performance
Contact Resistance Initial: 40 mΩ Max.
Variation: 10 mΩ Max.
Dielectric Withstand Voltage 100V AC for 1 minute
Insulation Resistance 100 MΩ Min
Rated Current 3A for VBUS; 1.25A for GND;
0.25A for Others
Mechanical Properties
Insertion Force 5-20N
Extraction Force Initial: 8-20N;
After testing: 6-20N
Lifespan 10,000 cycles
Working Temperature -25°C to +80°C
USB Type-C Female Connector

USB Type-C Female Connector

Dual Row SMT 6-Pin Molded Type

Features:

  • ✅ Dual Row SMT Design
    The dual-row surface mount layout provides strong solder joints and excellent structural support, ensuring reliable connection during assembly and long-term use.
  • ✅ 6-Pin Molded Construction
    Features a 6-pin reinforced molded housing, enhancing mechanical stability, alignment precision, and anti-deformation performance during high-speed production.
  • ✅ High-Speed Data & Power Transmission
    Our Type-C Female Connector supports USB 3.x / PD fast charging and high-speed data transfer, making it ideal for devices requiring efficient and reliable power and communication interfaces.
  • ✅ Durable and Reliable Materials
    Manufactured with high-temperature-resistant LCP/PA plastic and copper alloy contacts with gold plating, ensuring superior conductivity, corrosion resistance, and durability.
  • ✅ Compact Design:
    Space-saving PCB mounting type, perfect for modern electronic devices.
